Arada Grate Bar (x1) for Casting AFS001

This individual cast iron firebar is a direct replacement for Casting AFS001, designed to fit a wide range of Arada, Aarrow, Hamlet, Stratford and Villager stoves. It forms part of the riddling grate, supporting the solid fuel bed and allowing ash to fall into the ashpan—ensuring efficient airflow and clean combustion. Ideal for replacing a damaged or missing bar without committing to a full set.

5-bar sets:

• Villager Puffin 4
• Villager Heron 5
• Hamlet Solution 5
• Hamlet Sherborne Compact
• Aarrow Ecoburn 5
• Hamlet Camborne Deluxe
• Nouveau 7

7-bar sets:

• Villager Duo 8

9-bar sets:

• Arada Ecoburn 9
• Hamlet Solution 9
• Hamlet Sherborne Medium
• Stratford SF50

11-bar sets:

• Stratford Ecoboiler 20 HE
• Stratford Ecoboiler 25 HE
• Hamlet Solution 11
• Villager Duo 12
• Villager Boiler 20
• Aarrow Ecoburn 11

📌 Other compatible models (bar quantity may vary):

ACORN4, ACORN5, APEX, ARL5M, ARL7M, ARL11M, AX1M/AX2M (S2 & S3), AX3M, AX4M, AX5M-INSET, ATH1M, ATH2M, ATH3M, ATH5M-INSET,
B5MU, B7MU, B11MU, B11W, BEC-5X, BEC-7X,
CAMDLC, CAMDLS, CAMDLMM, CAMDLCM-G2, CAMDLSM-G2, CAMDLMM-G2,
CARCM, CARSM, CARMM,
EB7HE–EB18HE (incl. all variants),
ECB5–ECB9 (WCE, MCE, INSET),
ECO5, ECO7, ECO9, EV7, EV11,
HARDY4M–5M (S3), HSB9–HSB16,
HERON5M (S2 & S3), PUFFIN4M (S2 & S3),
SEB20,
SHBCM, SHBSM, SHBMM (incl. G2 variants),
SIGN5/5M/5W, SIGNI5M/5W,
SF30, SF50, SM30–SM50,
SOL5–SOL9 (incl. CE, MCE, INSET, S2, SC, WS variants),
TF30B, TF50B,
V5-DUO, VB12-DUO, VHAM,
VALOR HAMLET

🔧 Specifications

• Quantity: 1 x Grate Bar
• Material: Cast Iron
• Length: Approx. 220mm
• Weight: ~0.89kg
• Casting Code: AFS001
• Supplied as a high-quality non-original compatible part

🔥 Why replace your grate bar?

Even a single cracked or warped firebar can disrupt airflow, hinder riddling, and reduce combustion efficiency. Replacing individual bars helps maintain performance and avoids premature wear on the remaining set—especially if your stove uses older NGB2B-style bars.
